1A88F Push-Open with Silent Soft-Closing Undermount Slide for Face Framed Cabinets (16mm)

1A88F Push-Open with Silent Soft-Closing Undermount Slide for Face Framed Cabinets (16mm)

Pronounced style, classic design
When simplicity and luxurious life-style is in harmony

The World's First Electric-Free All-Mechanical Design
King Slide flawlessly combined the touch-to-open and soft-closing technologies in 1A88. Unlike other brands, King Slide uses all-mechanical patent pending design that will not only save electricity but also promote green technology. With King Slide's all-mechanical design, 1A88 concocts your personal style and green life!

Awarded Prizes
‧ Best of KBIS of Kitchen Gold Award
‧ IWF 2010 Challengers Award Winner
‧ TAIWAN Excellence 2011

【Specifications】
• Length: 305 / 381 / 457 / 533mm
12" / 15" / 18" / 21"
• Travel: Full Extension
• Maximum Drawer Side Thickness: 16mm(5/8")
• Max. Loading Capacity: 34 kg(75 lb)/pair
• Mount: Undermount
• Material: Galvanized Steel
• Height Adjustment: +3.5mm
• Side Space Adjustment: +0.5mm / -1mm
• Depth Adjustment: +1/-1mm
• Lifecycle: 100,000
• Packing: Unit Packed in 2 pairs/carton

【Features】
• Handle-free, push-open function.
• Enhanced silent soft-closing feature with light opening force.
• Durable damping system with fast response capability.
• Safe, user-friendly and energy saving due to electricity-free, all mechanical design.
• Undermounted concealed runner with full extension travel length.
• Ultra smooth gliding motion with high rigidity and stability.
• Ergonomic adjustment provide tool-less height and depth adjustments - compensate for minor tolerances thereby reducing installation complexity.
• Simple assembly and removal of drawer with the front release latch.

【Applications】

• For Face Frame Cabinet : Kitchen Furniture, Kitchen Cabinetry, Home Cabinetry and Box Drawers



SKU Total Length Cabinet Depth With Bracket Cabinet Depth With Bracket Slide Length Packing Order
1A88F305 305 mm ( 12 in ) 2 Set Unit package w/ lock device & rear bracket
1A88F381 381 mm ( 15 in ) 2 Set Unit package w/ lock device & rear bracket
1A88F457 457 mm ( 18 in ) 2 Set Unit package w/ lock device & rear bracket
1A88F533 533 mm ( 21 in ) 2 Set Unit package w/ lock device & rear bracket
